V-Packing
For Piston and Rod Seals
|
| Material |
Pressure (Bar) |
Temp. ( ̊̊c) |
Speed (m/s) |
| NBR + Fabric |
400 |
- |
30 |
0.5 |
| + |
120 |

Material : Fabric Reinforced NBR, Black Color (1 + 5 + 1)
| Part Number |
Nominal Size of Packing |
ID
(Ød) |
OD
(ØD) |
HEIGHT
(B) |
| |
|
|
Unit : mm. |
| V 12-25-26 |
12 |
25 |
26 |
| V 14-24-20 |
14 |
24 |
20 |
| V 16-26-20 |
16 |
26 |
20 |
| V 20-30-20 |
20 |
30 |
20 |
| V 20-32-24 |
20 |
32 |
24 |
| V 20-35-30 |
20 |
36 |
30 |
| V 22-32-20 |
22 |
32 |
20 |
| V 25-38-25.75 |
25 |
38 |
25.75 |
| V 25-40-26.25 |
25 |
40 |
26.25 |
| V 28-40-24.5 |
28 |
40 |
24.5 |
| V 32-45-26 |
32 |
45 |
26 |
| V 35-50-26.25 |
35 |
50 |
26.25 |
| V 35-55-40 |
35 |
55 |
40 |
| V 36-51-26.25 |
36 |
51 |
26.25 |
| V 40-52-30 |
40 |
52 |
30 |
| V 40-56-27.43 |
40 |
56 |
27.43 |
| V 40-60-30 |
40 |
60 |
30 |
| V 45-60-30 |
45 |
60 |
30 |
| V 50-65-22.5 |
50 |
65 |
22.5 |
| V 50-70-30 |
50 |
70 |
30 |
| V 55-70-22.5 |
55 |
70 |
22.5 |
| V 55-75-30 |
55 |
75 |
30 |
| V 55-67-24 |
55 |
67 |
24 |
| V 56-71-22.5 |
56 |
71 |
22.5 |
| V 56-76-37 |
56 |
76 |
37 |
| V 56-72-49 |
56 |
72 |
49 |
| V 60-75-22.5 |
60 |
75 |
22.5 |
| V 60-76-32 |
60 |
76 |
32 |
| V 60-80-37 |
60 |
80 |
37 |
| V 60-85-37 |
60 |
85 |
37 |
| V 63-78-22.5 |
63 |
78 |
22.5 |
| V 63-83-37 |
63 |
83 |
37 |
| V 63.5-78-40 |
63.5 |
78 |
40 |
| V 65-80-22.5 |
65 |
80 |
22.5 |
| V 65-85-40 |
65 |
85 |
40 |
| V 70-85-22.5 |
70 |
85 |
22.5 |
| V 70-90-40 |
70 |
90 |
40 |
| V 70-95-50 |
70 |
95 |
50 |
| V 75-90-22.5 |
75 |
90 |
22.5 |
| V 75-95-40 |
75 |
95 |
40 |
| V 75-87-25 |
75 |
87 |
25 |
| V 75-100-34 |
75 |
100 |
34 |
| V 80-95-22.5 |
80 |
95 |
22.5 |
| V 80-100-40 |
80 |
100 |
40 |
| V 85-100-22.5 |
85 |
100 |
22.5 |
| V 85-105-40 |
85 |
105 |
40 |
| V 90-105-22.5 |
90 |
105 |
22.5 |
| V 90-110-40 |
90 |
110 |
40 |
| V 90-110-26 |
90 |
110 |
26 |
| V 95-120-50 |
95 |
120 |
50 |
| |
|
|
|
Material : Fabric Reinforced NBR, Black Color (1 + 5 + 1) |
| Part Number |
Nominal Size of Packing |
ID
(Ød) |
OD
(ØD) |
HEIGHT
(B) |
| |
|
|
Unit : mm. |
| V 100-115-30 |
100 |
115 |
30 |
| V 100-120-40 |
100 |
120 |
40 |
| V 100-125-50 |
100 |
125 |
50 |
| V 100-130-60 |
100 |
130 |
60 |
| V 105-120-30 |
105 |
120 |
30 |
| V 105-125-40 |
105 |
125 |
40 |
| V 105-130-40 |
105 |
130 |
40 |
| V 110-125-30 |
110 |
125 |
30 |
| V 110-130-40 |
110 |
130 |
40 |
| V 110-140-60 |
110 |
140 |
60 |
| V 112-132-40 |
112 |
132 |
40 |
| V 115-130-30 |
115 |
130 |
30 |
| V 115-140-46 |
115 |
140 |
46 |
| V 115-135-30 |
115 |
135 |
30 |
| V 120-140-49 |
120 |
140 |
49 |
| V 120-145-46 |
120 |
145 |
46 |
| V 120-150-60 |
120 |
150 |
60 |
| V 125-140-30 |
125 |
140 |
30 |
| V 125-150-46 |
125 |
150 |
46 |
| V 135-160-55 |
135 |
160 |
55 |
| V 136-160-40 |
136 |
160 |
40 |
| V 140-155-30 |
140 |
155 |
30 |
| V 140-160-40 |
140 |
160 |
40 |
| V 140-165-50 |
140 |
165 |
50 |
| V 150-170-40 |
150 |
170 |
40 |
| V 150-175-50 |
150 |
175 |
50 |
| V 150-180-58 |
150 |
180 |
58 |
| V 160-180-40 |
160 |
180 |
40 |
| V 160-185-50 |
160 |
185 |
50 |
| V 160-190-60 |
160 |
190 |
60 |
| V 165-195-60 |
165 |
195 |
60 |
| V 170-190-30 |
170 |
190 |
30 |
| V 170-195-50 |
170 |
195 |
50 |
| V 170-200-49.5 |
170 |
200 |
49.5 |
| V 175-205-60 |
175 |
205 |
60 |
| V 180-200-40 |
180 |
200 |
40 |
| V 180-205-50 |
180 |
205 |
50 |
| V 180-210-60 |
180 |
210 |
60 |
| V 190-210-40 |
190 |
210 |
40 |
| V 200-220-40 |
200 |
220 |
40 |
| V 200-225-50 |
200 |
225 |
50 |
| V 200-230-60 |
200 |
230 |
60 |
| V 215-245-60 |
215 |
245 |
60 |
| V 220-250-60 |
220 |
250 |
60 |
| V 250-275-50 |
250 |
275 |
50 |
| V 265-285-40 |
265 |
285 |
40 |
| V 270-300-60 |
270 |
300 |
60 |
| V 280-320-80 |
280 |
320 |
80 |
| V 350-380-52.4 |
350 |
380 |
52.4 |
| V 350-390-80 |
350 |
390 |
80 |
| V 355-387-64 |
355 |
387 |
64 |
| V 360-400-80 |
360 |
400 |
80 |
| V 375-407-64 |
375 |
407 |
64 |
| V 425-475-100 |
425 |
475 |
100 |
| |
|
|
|
|
 |
